Description
EPA/ATEX personnel’s grounding tester
STANDSTAT II – Test station for anti-static ESD safe wrist straps and footwear, equipped with footplate, support stand and instructions panel.
Practical and convenient tool, it performs a complete test of grounding equipment in a few seconds.
Thanks to an internal relay, it can be used to open an electric lock if test results are passed.
Available models: Compliant with IEC 61340-5-1 requirements for EPA areas (El.Mi code 149971E), Compliant with ATEX requirements (El.Mi code 149971X).
Testing modes:
- WRIST STRAP ONLY
- FOOTWEAR ONLY
- Simoultaneous measurement of WRIST STRAP AND FOOTWEAR
- HANDS-FREE (footwear only): if footwear measurements (both right and left) pass the test, the internal relay output enables access to the EPA area without pressing any button (ATTENTION: this option is available only when using the 149971H external power supply (to be purchased separately).
Specifications:
- Separated measurement of right and left footwear
- Test can be executed at 50 V and at 100 V for better accuracy
- Power supply: Battery (9 V).
Limit values:
| LOW |
HIGH |
|
| Wrist strap | 750 KOhm | 35 MOhm |
| Footwear | 0 – 100 KOhm (selectable) |
EPA MODEL: 10 – 35 – 40 – 100 – 200 MOhm (selectable) – ATEX MODEL: 1 GOhm |
Scope of supply: STANDSTAT II test station, 1 x Battery (9 V), ISO 9000 traceable calibration certificate, User manual (English).
Available accessories (NOT included): External power supply (El.Mi product no.: 149971H).
