Description
Weller WXA 2010 hot air station
WXA 2010 – Two-channel digital hot-air station, 200 W (255 W) / 230 V.
Requires external compressed air supply (NOT included). Allows simultaneous operation of 2 soldering tools.
Weller product no.: T0053430399N.
Specifications
Scope of supply:
- WXA 2 (T0053425699N) – Multifunction power unit with 2 channels for soldering and hot air applications, 200 W (255W)
- WXHAP 200 (T0052711999N) – Hot air iron 200 W / 24 V Equipped with R 06 round nozzle, Ø 3.0 mm
- R04 (T0058727821N) – Round nozzle, Ø 1.2 mm
- WDH 30 (T0051515299N) – Safety rest with dry cleaner.
Specifications
- Channels: 2
- Power: 200 W (255 W)
- Voltage: 230 V
- Temperature range (depends on tool): 100 – 550 °C (150 – 999 °F )
- Temperature stability: ± 2 °C (± 4 °F)
- Temperature accuracy: ± 9 °C (± 17 °F)
- Max. hot air flow rate (depends on tool): 15 l/min
- Capacity: 20 l/min
- Air consumption: 20 l/min
- Compressed air connection: Outer diameter 6mm (0, 24 “); Oil-free, dry compressed air
- USB port: Yes, USB interface in front of firmware updates, parameterization and monitoring (USB interface supports all standard USB flash drive types)
- Display: Backlighting, 255 x 128 dots
- Dimensions (LxLxH): 174 x 154 x 135 mm
- Fuse: T2A
- WX-compatible: Yes
- ESD safe
- Power cable: EMEA.
ATTENTION: DISCONTINUED PRODUCT
OFFER VALID WHILE STOCK LASTS
